MINI AIR COMPRESSOR (DIAPHRAGM TYPE)

Model #

MC-6603TFRGP

Horse power

 1/8 HP

Displacement

 50HP - 21 L/Min (0.75CFM);

 60HP - 25 L/Min (0.90CFM)

Free Speed

 50HZ - 1,400 RPM;

 60HZ - 1,700 RPM

Max. pressure

 3.5 KG/CM² (50 PSI)

Noise

 58 dB

Outlet size

 1/8"

Weight

 8 kg (17.6 lb)

Tank

 3.5L

Dimension

 340(L)x 125(W)x 340(H) mm

Pressure switch setting

 Cut-out - 2.8 kg/cm² (40 psi)

 Cut-in - 2.1 kg/cm² (30 psi)
