Pneumatic insert installation tool
1. Thread tool into fastener.
2. Run tool to collapse fastener. Reverse tool to release.
3. Assemble.
4. Side exhaust.
PNEUMATIC INSERT INSTALLATION TOOL SIDE EXHAUST
Model #6902
|
Model No. |
Riveting nut (Round) |
Riveting nut (Hex) |
Free Speed |
Air Consumption |
Overall Length |
Air Inlet |
Net Weight |
Packing Pcs/Ctn/G.W/Cuft (kgs) |
|||
|
r.p.m |
cfm |
I/min |
inch |
mm |
N.P.T |
lbs |
kgs |
||||
|
ST-6901 |
1/4”,3/16”5/32”,M3,M5,M6 |
3/16”,M3, M4, M5 |
700 |
8 |
226 |
7.87 |
200 |
1/4” |
2.65 |
1.2 |
10/Ctn/14/1.0’ |
|
ST-6902 |
1/4”,5/6”,3/8”,M5,M6,M8,M10 |
1/4",5/16",M6,M8 |
450 |
8 |
226 |
8.27 |
210 |
1/4” |
3.97 |
1.8 |
5/Ctn/17/1.0’ |
|
ST-6340 |
M10,M12,3/8”-16,3/8”-24,1/2”-13 |
M10,3/8”-16,3/8”-24 |
200 |
8 |
226 |
8.66 |
220 |
1/4” |
2.87 |
1.3 |
10/Ctn/15.5/1.15’ |
|
ST-6341 |
M6,M8,M10,1/4”-20,5/16”-18,3/8”-16 |
M5,M6,1/4”-20 |
360 |
8 |
226 |
8.27 |
210 |
1/4” |
2.76 |
1.25 |
10/Ctn/14.5/1.15’ |
|
ST-6341Q |
M6,M8,M10,1/4”-20,5/16”-18,3/8”-16 |
M5,M6,1/4”-20 |
360 |
8 |
226 |
8.66 |
220 |
1/4” |
2.76 |
1.25 |
10/Ctn/14.5/1.15’ |
|
ST-6343 |
M3,M4,M5,#6-32,#8-32,#10-24,#10-32 M6,1/4”-20 |
M3,M4, #6-32, #8-32, #10-24 |
1200 |
8 |
226 |
7.28 |
185 |
1/4” |
2.09 |
0.95 |
10/Ctn/12.5/0.85’ |
|
ST- 6343Q |
M3,M4,M5,#6-32,#8-32,#10-24,#10-32 M6,1/4”-20 |
M3,M4, #6-32, #8-32, #10-24 |
1200 |
8 |
226 |
7.28 |
185 |
1/4” |
2.09 |
0.95 |
10/Ctn/12.5/0.85’
|
** There is various kind of rivet nut each model, please specify the Nosehead size when ordering.
All tools are available I both Aluminum threaded insert and steel threaded insert.
█ Only available in Aluminum threaded insert.
Application:
Suitable for Aluminum & Iron riveting nut.
